Recording data on networks M-Bus.
The device CPTM_Bus is a model that allows to read and record data from
all instrumentation in M-Bus standard architecture, in a stand-alone
mode trough Computherm's peripheral device or by any other system
that supports this protocol. The M-Bus protocol is an open international
standard that allows to exchange information from the slaves (gauges
and counters M-Bus) to the master (network operator or CPTM-Bus).
The management and the decoding of M.Bus protocol conforms to UNI
EN 1434 regulations.
The device can be ordered in different versions: Master, Slave and Level converter:
| Master | Slave | Level converter |
|---|
 |
 |
 |
In the master and in the slave version there is a function to record the
historical data from 250 instruments in a range of time programmable by
hour or day. For example: a daily record of 250 instruments will go on
2 years.
The support with removable memory allows the configuration and the record
of data. In case of failure the support can be installed in a new
equipment, preserving the settings and the recorded data, assuring
security and continuity of service.
.
Moreover, an efficient system of differential unloading favors time and
resources saving (specially by GSM).
Data logger CPTM-Bus Module for Din rail remotely controllable The device CPTM-BUS Master can be used independently, in direct connection to the local Pc or by modem GSM. It's also possible to control completely a thermal power plant using a device CPTM-Bus and a device TaX3 Available configurations of CPTM-Bus01: | Model | Gauges | Configuration |
|---|
| 60AL | 60 | Master | | 60MD | 60 | Master con modem GSM | | 60T6 | 60 | Slave per telegestione T6fx | | 60LC232 | 60 | LevelConverter RS232 | | 60LC485 | 60 | LevelConverter RS485 | | 120AL | 120 | Master | | 120MD | 120 | Master con modem GSM | | 120T6 | 120 | Slave per telegestione T6fx | | 120LC232 | 120 | LevelConverter RS232 | | 120LC485 | 120 | LevelConverter RS485 | | 250AL | 250 | Master | | 250MD | 250 | Master con modem GSM | | 250T6 | 250 | Slave per telegestione T6fx | | 250LC232 | 250 | LevelConverter RS232 | | 250LC485 | 250 | LevelConverter RS485 |
|
